Yamaha RX - King 135 1993

Yamaha RX King 135 1993 Original Version

Made In Indonesia

Author : Yohanes C.B
Editor : Sefa Prasetia
replace : Sanchez

Specifications RX-King (1983-2006)

ENGINE
Engine Type: 2 Step, Air Cooled
Diameter x Stroke: 58.0 x 50.0 mm
Cylinder Volume: 132 cc
Comparison Compression: 6.9: 1
Clutch: Manual, Wet, multipleplatform
Cylinder arrangement: One / Slant
Transmission: 5 speed
Transmission Operation pattern: 1-N-2-3-4-5
Carburetor: MIKUNI VM 26 x 1
Two stroke Oil Capacity: 1 Liter
Battery: GM 3-3B / 12.3
Spark: 8HS BP-10
Ignition system: CDI
Lubricant system: Autolube

SUSPENSION / Tyre
Suspension Front: Telescopic
Rear Suspension: Swing Arm
Front Tire Size: 2.75-18-4 PR
Rear Tire Size: 3.00-18-4 PR

DIMENSIONS
Length x Width x Height: 1970 mm x 735 mm x 1,065 mm
Distance Axis Wheels: 1,245 mm
Seat height: 770 mm
Lowest distance to the Land: 160 mm
Fuel Tank Capacity: 9.5 Liter
Empty weight: 100 kg

CHASSIS

Frame Type: Double Cradle

PERFORMANCE

Dimensions LxWxH: 1970 x 735 x 1065 mm
Starter system: Kick
Maximum Power 18.5 PS / 9000 RPM
Maximum Torque: 1:54 kgf.m / 8000 RPM

BRAKING SYSTEM
Brakes Front: Disc Double Piston
Brakes Rear: Drum

(Source : AKAB Rx-King CLUB Ciamis )

:3 i hope you will enjoy our mod
